TE 6-A36 Cordless rotary hammer

Cordless rotary hammer TE 6-A36 box #2098503

Configurator
Technical Data
Documents
Features & Applications
Related Products
Services
TE 6-A36 G04 (78413)
TE 6-A36 (82960)
TE 6-A36 (82963)
TE 6-A36 (82962)
TE 6-A36 (82972)
TE 6-A36 (82971)

Powerful D-grip 36V cordless rotary hammer with superior concrete drilling and chipping performance

  • Weight according to EPTA Procedure 01/2003: 3.7 kg
  • Optimum hammer drilling range: 6 - 16 mm
  • Single impact energy: 2.5 J

Customers also searched for te 6a, cordless drill, cordless rotary or 36v.

Choose options

Pack size
  • 1 pc
 Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Ex Vat and Packaging/Forwarding charges
AED 5,152.17
AED 5,152.17
/
1 Piece

Technical Data

Weight according to EPTA Procedure 01/2003
3.7 kg
Optimum hammer drilling range
6 - 16 mm
Single impact energy
2.5 J
Hammer drilling diameter range
4 - 20 mm
Hammer drilling RPM
1050 rpm
Full hammering frequency
5100 impacts/minute
Functionality
Active Vibration Reduction (AVR), Integrated Dust Removal System (DRS), Removable chuck, LED working light, Reverse mode, Depth gauge
Triaxial vibration value for hammer drilling into concrete (ah,HD)
16.8 m/s² 1
Triaxial vibration for chiselling in concrete
8.1 m/s² 2
A-weighted emission sound power level
102 dB (A) 3
A-weighted emission sound pressure level
91 dB (A) 4
Dust removal system available
TE DRS-6-A, TE DRS-D, TE DRS-S, DCD
  1. According to the applicable product standard (see the Operating Instruction for more details)
  2. According to the applicable product standard (see the Operating Instruction for more details)
  3. According to the applicable product standard (see Operating Instruction for more details)
  4. According to the applicable product standard (see Operating Instruction for more details)

Documents

Material safety datasheet
Operating Instruction
pdf Material safety datasheet Hilti Grease (AR) [ 927.2 KB ]
pdf Material safety datasheet Hilti Grease (EN) [ 735.3 KB ]

Features & Applications

Features

  • Extremely powerful rotary hammer, designed for serial concrete drilling
  • Very convenient and lightweight for superior handling
  • High run time flexibility thanks to powerful and fast-charging 36V Li-Ion batteries
  • Active Vibration Reduction (AVR) system designed to increase user comfort and productivity
  • Virtually dustless drilling with the DRS-6-A dust removal system

Applications

  • Drilling and hammer drilling in concrete and masonry
  • Occasional drilling in wood and steel with optional quick-release chuck
  • Screwdriving using the special bit holder with TE-C (SDS Plus) connection end
  • Drilling in concrete in clean areas using the DRS-6-A (02) integrated dust removal system
  • Light chiselling

Services

Hilti Tool Service

  • 3 or free: get the tool serviced and cleaned in 3 days flat or there is no charge
  • Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
  • After the no-cost period, repair costs are capped
  • Product warranty against parts and manufacturing irregularities for as long as we service the tool
  • Product warranty against parts and manufacturing irregularities for 20 years
More information about Tool Services

Fleet Management

  • Individual labels and online visibility provide tool fleet transparency
  • Monthly usage fee covering all tool, service and repair costs helping to ensure absolute cost control and back-office efficiency.
  • High-performing tools and latest technology help to increase jobsite productivity.
  • Loan tools during repair to reduce downtime.
  • Temporary tools for peak times and special applications help to reduce investments.
More information about Fleet Management

LifeTime Services

  • No repair costs for 2 years from date of purchase, including parts subject to wear and tear, shipping and labour
  • After the no-cost period, repair costs are capped for as long as we service the tool
  • 1-month no-repair-cost period again after every paid repair
  • Materials and workmanship warranty over the entire life of the tool
  • Pick-up and delivery service
More information about LifeTime Services
