TE 30-A36 Cordless rotary hammer

Kit TE 30-A36 + TE-CX 16/27 #2390994

Powerful SDS Plus (TE-C) cordless rotary hammer for heavy-duty concrete drilling and corrective chiselling

Weight according to EPTA Procedure 01/2003: 5.1 kg
Optimum hammer drilling range: 10 - 20 mm
Single impact energy: 3.6 J

Choose options

Pack size

1 pc

Product options

Quantity

Packs

Total Pieces

You can not see your company prices

Please Log in or register to see your company prices.

Ex Vat and Packaging/Forwarding charges

AED 6,896.86

1 Piece

Technical Data

Weight according to EPTA Procedure 01/2003

5.1 kg

Optimum hammer drilling range

10 - 20 mm

Single impact energy

3.6 J

Hammer drilling diameter range

4 - 28 mm

Hammer drilling RPM

850 rpm

Full hammering frequency

4500 impacts/minute

Functionality

Active Torque Control (ATC), Active Vibration Reduction (AVR), Removable chuck, Reverse mode, Depth gauge

Triaxial vibration value for hammer drilling into concrete (ah,HD)

10.3 m/s² ¹

Triaxial vibration for chiselling in concrete

8.5 m/s² ²

A-weighted emission sound power level

99 dB (A) ³

A-weighted emission sound pressure level

95 dB (A) ⁴

Dust removal system available

TE DRS-D, TE DRS-S

According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)

Documents

pdf Material safety datasheet Hilti Grease (AR) [ 927.2 KB ]

Download

pdf Material safety datasheet Hilti Grease (EN) [ 735.3 KB ]

Download

Features & Applications

Features

Active Torque Control (ATC) stops the tool body from spinning uncontrollably if the drill bit jams – helping to reduce a common safety hazard
Active Vibration Reduction (AVR) makes the rotary hammer less tiring to use – helping to increase daily productivity
Brushless motor for exceptionally high performance and superior system efficiency
Quick-change chucks – changing bits is fast and tool-free
Extra-long lifetime thanks to a highly robust chuck, motor components and casing

Applications

Drilling anchor holes and through-holes in concrete and masonry, diameter range 4-28 mm, recommended range 10-20 mm
Drilling holes for rebar doweling, diameter range 4-28 mm, recommended range 10-20 mm
Corrective chiselling
Drilling in wood, metal and other materials using the quick-release chuck
Driving and removing screws using the quick-release chuck
