Software for analyzing and visualizing data from Ferroscan concrete scanners and X-Scan detection systems

  • Supported operating system: Windows 7, Windows 8, Windows 10, Windows 11
  • Security and authorizations: Hilti-signed software
  • Minimum disc space required: 250 MB

Technical Data

Supported operating system
Windows 7, Windows 8, Windows 10, Windows 11
Security and authorizations
Hilti-signed software
Minimum disc space required
250 MB
Memory (RAM) requirements
2 GB
Graphic card requirements
OpenGL 3.2 support

Features & Applications

Features

  • Analyze and model your concrete scans with one software program
  • Simplify structural analysis using visualization tools
  • Compatible with popular BIM, CAD and PROFIS Anchor software
  • Help avoid damage while drilling or sawing – even before work begins on site
  • Get all the facts for more accurate bidding and scheduling

Applications

  • Full data processing from raw data to 3D models, including 2D and 3D plan views or cross-sectional images. With PROFIS Detection Office, you can easily create an accurate 3D model of hidden objects within a concrete structure. The software is BIM-ready in order to facilitate more efficient, accurate, cost-effective and reliable project planning.
  • PROFIS Detection Office supports three-sensor data overlay – radar, EM and Ferroscan – for easy target object classification and depth calibration
  • Supports data export in various formats for use with popular design applications such as AutoCAD®, Trimble SketchUp® and many more. Supported export formats include: DXF, COLLADA, PLY, X3D, BMP, JPG. You can import X3D scan files in PROFIS Anchors to support collision-free anchor and baseplate design.
  • Scan positions can be labelled with building coordinates and exported for accurate scan placement in design files or repositioned later on-site with layout tools.
  • Having the best possible structural information in advance allows more accurate communication and tendering. Easy-to-understand structural reports help you avoid unexpected remedial works and damage during drilling, coring or sawing.

For approval or certificate information, please see individual items.
