MQV-R Channel connector

Rail support MQV-2/2 D-14-R #304033

Stainless steel (A4) channel connector used as a longitudinal extender for MQ strut channels

Tightening torque: 40 Nm
Material composition: Stainless steel, 1.4404 (A4) – EN 10088, AISI 316L
Surface finish: Outdoor Plus - Stainless Steel

Customers also searched for rail supports, installation supports, stainless steel connectors, SS connectors or metal connectors.

Choose options

Pack size

10 pc

Product options

Quantity

Packs

Total Piece

You can not see your company prices

Please Log in or register to see your company prices.

Ex Vat and Packaging/Forwarding charges

AED 5,244.75

AED 524.48 / 1 Piece

Technical Data

Tightening torque

40 Nm

Material composition

Stainless steel, 1.4404 (A4) – EN 10088, AISI 316L

Surface finish

Outdoor Plus - Stainless Steel

Material thickness

4 mm

Environmental conditions

Outdoor high pollution (C4 – high / C5)

Weight

440 g

Documents

Features & Applications

Features

Universal – complete many different applications using few parts
Adjustable – easily fitted and repositioned along strut channels
Compatible with MQN-R push button channel connectors – for much faster, adaptable assembly

Applications

Connecting strut channels to various base materials
Connecting two MQ strut channels together
Compatible with multiple MQ strut channels
