MQA-B pipe clamp saddle

Pipe ring saddle MT-AS FS M16 #2199454

LCG001772_v1 (187398)
14676.eps

Ultimate galvanised pipe clamp saddle – fire-tested according to ETA

  • Approvals: ETA
  • Product class: Premium
  • Tightening torque: 40 Nm
premium

Customers also searched for pipe supports, installing pipes, pipe rings, pipe clamps or connectors.

Choose options

Thread connection - M
  • M16
Pack size
  • 50 pc
 Product options
Quantity
Packs
Total Pieces
50
You can not see your company prices

Please Log in or register to see your company prices.

Ex Vat and Packaging/Forwarding charges
AED 1,496.62
AED 29.93
/
1 Piece

Technical Data

Approvals
ETA
Product class
Premium
Tightening torque
40 Nm
Thread connection - M
M16
Material composition
Nut: C4C - DIN EN 10263, Plate: S 235 JRG2 - DIN EN 10025, Plastic: PBT
Surface finish
Indoor Coated - Electro galvanised
Environmental conditions
Dry indoor conditions (C1) Indoor with temporary condensation (C2)
Weight
83 g

Documents

pdf ETA_Modulare_Schienensysteme_V1.4_de, German [ 14.2 MB ]
pdf ETA-23-0103 Static Fire Saddle nuts, English [ 2 MB ]

Features & Applications

Features

  • Quick connection of threaded components to the open side of MQ strut channels
  • Easy installation and positioning within MQ strut channel openings
  • Single, compact part – for higher productivity and flexibility
  • Various thread sizes available
  • Moveable

Applications

  • Fastening pipes and air ducts
  • Fastening cable trays and cable baskets
  • Recommended for use in dry, interior environments
  • Applications with fire requirements
