Pipe clamp saddle for connecting threaded components to MT channels

  • Material composition: S235JR, DD11 MOD, Amstrong 240MC
  • Material and coating: Carbon steel - indoor coated
  • Material thickness: 2.5 mm

Technical Data

Material composition
S235JR, DD11 MOD, Amstrong 240MC
Material and coating
Carbon steel - indoor coated
Material thickness
2.5 mm
Surface finish
Indoor Coated - Electro galvanised
Tightening torque
18 Nm

Documents

Features & Applications

Features

  • Quick connection of threaded components to the open side of MT strut channels
  • Easy installation and positioning within MT strut channel openings
  • Single, compact part – for higher productivity and flexibility
  • Various thread sizes available
  • Robust single-part design without plastic components

Applications

  • Fastening pipes to MEP support structures
  • Fastening air ducts to MEP support systems
  • Recommended for use in dry, interior environments

For approval or certificate information, please see individual items.
