S-BT MF Screw-in stud

Configurator
Technical Data
Documents
Features & Applications
Related Products
S-BT-MF M10/15 AN 6, S-BT-MF W10/15 AN 6 (83251)
S-BT-MF (85510)
S-BT-MF (85509)
S-BT-MF (85513)
S-BT-MF (85497)
S-BT-MF (85504)

Threaded screw-in stud (carbon steel, Metric or Whitworth thread) for multi-purpose fastenings on steel in mildly corrosive environments

  • Base materials: Steel
  • Minimum thickness of base material (steel): 6 mm
  • Corrosion protection: Duplex coating, equivalent to 45 µm hot-dip galvanised
ultimate

Customers also searched for Composite studs, Stainless stud fasteners, Stainless stud nails, Blunt tip screw studs or Multi-fastening studs.

Choose options

Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Ex Vat and Packaging/Forwarding charges
Price loading error occured

Please contact us

Technical Data

Base materials
Steel
Minimum thickness of base material (steel)
6 mm
Corrosion protection
Duplex coating, equivalent to 45 µm hot-dip galvanised
Environmental conditions
Outdoor, mildly corrosive
Material
Carbon steel
Approvals
ABS, BV, DNV, ETA, ICC-ES, LR, RMR
Product class
Ultimate

Documents

Approval document
Technical information
Reference document
pdf ETA-20/0530_S-BT_2020.09.18_en, German, English [ 3.3 MB ]
pdf RINA Type Approval FPE278318CS/001 for S-BT-MR / -MF, S-BT-GR / -GF, S-BT-ER / -EF, X-FCM-R (NG), X-FCM-M (NG) and X-FCS-R fastening system in off-shore and shipbuilding application, English [ 108.1 KB ]
pdf ABS Type Approval 21-2140400-PDA for S-BT fastening system in off-shore and shipbuilding application, English [ 1.7 MB ]
pdf LR Type Approval LR21394055TA for S-BT fastening system in off-shore, shipbuilding and industrial application, English [ 470.9 KB ]

Features & Applications

Features

  • The S-BT MF is easier and more reliable – no electric supply cords or heavy equipment needed for installation
  • Suitable for use in mildly corrosive environments (C3) on coated steel
  • Easy installation in tight spaces
  • No rework on coated steel
  • Compatible with Hilti MQ and MC installation channels

Applications

  • General fastenings on steel structure with a thickness of 6 mm (1/4") and greater
  • Fastening cable ladders using channels or hold-down/expansion guide clips
  • Fastening cable trays and cable runs using channels or conduit clips
  • Fastening junction boxes, switchgear and instrumentation panels directly or using channels
  • Fastening lighting fixtures, signage etc.

For approval or certificate information, please see individual items.
